Step-by-Step Guide to Attaching IAM Roles to EC2 Instances

IAM roles provide temporary permissions to EC2 instances to interact with AWS services without embedding credentials in the application.

Step 1: Create an IAM Role

1. Go to the IAM Console: Navigate to IAM Roles.

2. Create Role:

   • Click the Create role button.

   • Select AWS service as the trusted entity type.

   • Choose EC2 under Use cases for other AWS services.

   • Click Next.

3. Select Permissions:

   • Select the appropriate policy for the permissions your EC2 instance needs.

     • Example: To allow read-only access to S3, attach the AmazonS3ReadOnlyAccess policy.

   • Click Next.

4. Configure Role:

   • Enter a descriptive name for the role (e.g., EC2S3ReadOnlyRole).

   • Add optional tags for identification (if needed).

   • Review the settings and click Create role.

Step 2: Attach IAM Role to EC2 Instance

1. Go to the EC2 Console: Navigate to EC2 Instances.

2. Select the Instance:

   • Choose the instance to attach the role.

3. Modify IAM Role:

   • Click Actions > Security > Modify IAM Role.

   • Select the IAM role created in Step 1.

4. Apply Changes:

   • Click Update IAM role.

Step 3: Verify IAM Role Attachment

• Check if an IAM role is attached to the instance:

     curl http://169.254.169.254/latest/meta-data/iam/info


  is used to retrieve information about the IAM role that is attached to an EC2 instance. This is part of the Instance Metadata Service (IMDS), a special HTTP endpoint available to EC2 instances, which provides metadata and dynamic data about the instance.

  • If a role is attached, the response will include details like the role name.

  • If no role is attached, you'll get an error or no data.

Breaking Down the Command

• curl: A command-line tool used to make HTTP requests.

• http://169.254.169.254: The IP address for the Instance Metadata Service. This is a reserved IP used internally within the EC2 instance.

• /latest/meta-data/iam/info: The specific path to retrieve IAM role information.

Step 4: Test Permissions Using AWS CLI

1. You can use AWS CLI or use EC2 instance connect, Ensure AWS CLI is installed on the instance (usually pre-installed on Amazon Linux).
   No Key Pair Required: In EC2 instance connect, You don't need to manage or use an SSH key pair for access.

2. Run commands to test permissions based on the IAM role's policies.

   Examples:

   • S3 Access: List S3 buckets (requires S3 permissions):

       aws s3 ls


   • EC2 Access: Describe running instances (requires EC2 permissions):

       aws ec2 describe-instances


   • CloudWatch Logs: View log groups (requires CloudWatch permissions):

       aws logs describe-log-groups


3. If the permissions are correctly configured, the command will execute successfully. Otherwise, you'll see an error like:

    An error occurred (AccessDenied) when calling the <API> operation: User: arn:aws:sts::123456789012:assumed-role/<role-name>/<session-name> is not authorized to perform: <API>


→ Inspect Temporary Credentials

• To view the temporary credentials provided by the IAM role:

    curl http://169.254.169.254/latest/meta-data/iam/security-credentials/<role-name>


  • Replace <role-name> with the IAM role name attached to the instance.

  • The response includes:

    • AccessKeyId

    • SecretAccessKey

    • Token

    • Expiration time

Common Debugging Tips

1. No IAM Role Attached:

   • Attach an appropriate IAM role to the instance using the Modify IAM Role action in the EC2 Console.

2. Policy Issues:

   • Ensure the IAM role has the correct permissions for the resources you are trying to access.

3. Region Mismatch:

   • Verify that your CLI commands are targeting the correct AWS region:

       aws configure set region <region-name>
